UNV UNIVIEW NVR502-32E-IX-G 2 HDD 32-Ch SUPER AI NVR Network Video Recorder
Description
Features
- Support Ultra H.265/H.265/H.264 video formats
- Support 32-channel input
- Support 2-ch HDMI, 2-ch VGA. HDMI up to 4K (3840×2160) resolution
- Support HDMI and VGA independent output
- Support up to 16 Megapixels resolution recording
- Support ANR technology to enhance the storage reliability when the network is disconnected
- Support SeekFree function: up to 16-ch with 3rd party IPC, up to 32-ch with UNV SIP/UMD IPC
- Support external USB keyboards
- Support Video Metadata, Diverse Algorithms by NVR
- Support cloud upgrade
Specification
| Model | NVR502-32E-IX-G |
| System Type | 32-Channel Network Video Recorder, 2 HDD |
| Video Compression | Ultra H.265 / H.265 / H.264 |
| Max IP Camera Inputs | 32 channels |
| Max Recording Resolution | Up to 16MP |
| Incoming Bandwidth | 192 Mbps |
| Outgoing Bandwidth | 192 Mbps |
| Decoding (Smart Off) | 32×1080p@30fps / 20×3MP@30fps / 8×4K@30fps / 4×16MP@30fps |
| Decoding (Smart On) | 32×720p@30fps / 16×1080p@30fps / 8×4MP@30fps / 4×4K@30fps / 2×16MP@30fps |
| HDMI Output | 2× HDMI (up to 4K@30Hz) |
| VGA Output | 2× VGA (independent output) |
| Audio | 1× RCA input, 2× RCA output, two-way audio |
| Live View Layout | 1 / 4 / 6 / 8 / 9 / 16 / 25 / 32 split |
| Playback | Up to 16-channel synchronous playback |
| Storage | 2× SATA HDD (up to 16TB each, max 32TB total) |
| Network Interface | 2× RJ45 10/100/1000 Mbps |
| USB Ports | 1× USB 2.0 (front), 2× USB 3.0 (rear) |
| Alarm I/O | 16 alarm inputs / 4 alarm outputs |
| Remote Users | Up to 128 users |
| Supported Protocols | TCP/IP, HTTP, HTTPS, DHCP, DNS, DDNS, NTP, SMTP, SNMP, IPv4/IPv6, UPnP, PPPoE |
| Smart Functions | Face detection, vehicle detection, intrusion detection, cross line detection, people counting, Ultra Motion Detection (UMD), AcuSearch |
| ANR | Supported |
| Power Supply | DC 12V / 5A |
| Power Consumption | ≤ 25W (without HDD) |
| Operating Temperature | -10°C to 55°C |
| Humidity | ≤ 90% RH (non-condensing) |
| Dimensions | 380 × 322.4 × 53 mm |
| Weight | Approx. 1.87 kg (without HDD) |
| Certifications | CE, FCC, UL, RoHS, WEEE |
What’s in the box
- 1 x NVR502-32E-IX-G Network Video Recorder
- 1 x Power Adapter (DC 12V)
- 1 x Power Cord
- 1 x USB Mouse
- 1 x SATA Data Cable
- 1 x SATA Power Cable
- 1 x Screw Pack for HDD Installation
- 1 x Quick Start Guide
- 1 x CD (User Manual / Software)
Warranty
3 Years Warranty
Local Manufacturer Warranty
